LED Street Lights > LD-09-SMD

Huazhibei LD-09SMD series LED street light, using high-quality aluminum die casting shell, simple structure,Streamline design, surface spray treatment, high temperature resistance, good weather resistance; optimal integration.The function of heat dissipation, beautiful appearance; using a unique two optical design of the lens, the whole Light intensity, uniform brightness; high temperature resistant silicone rubber seal, seal better equipped with high;A low loss chip imported light source, high thermal conductivity, low luminous decay, pure light color, no ghosting;Isolation of high precision IC control drive, constant current precision, high conversion rate, longer service life.

Applications: highway, city streets, bridges, tunnels, underground tunnels, underground parking lot, railway square, etc.!

 Characteristic Parameter:

Model No.

(W)

Power



(V)

Working Voltage

(λ)

Power Factor

(lm)

Luminous Flux

 (Ra)

CRI

(K)

CCT

(°)

Beam Angle

(IP)

IP Rate

(℃)

ambient temperature

Lamp structure

LD-09SMD-12W

12

AC85-265

﹥0.5

960

﹥70

2700-6800

120/140

65

-20℃~+50℃

12 series 1 parallel

LD-09SMD-24W

24

AC85-265

﹥0.5

1920

﹥70

2700-6800

120/140

65

-20℃~+50℃

12 series 2 parallel

LD-09SMD-50W

50

AC85-265

﹥0.9

4000

﹥70

2700-6800

120/140

65

-20℃~+50℃

10 series 5 parallel

LD-09SMD-60W

60

AC85-265

﹥0.9

4800

﹥70

2700-6800

120/140

65

-20℃~+50℃

10 series 6 parallel

LD-09SMD-80W

80

AC85-265

﹥0.9

6400

﹥70

2700-6800

120/140

65

-20℃~+50℃

10 series 8 parallel

Note: the scope of power error is about 10%; the range of flux error is -10%, some warm white luminous flux will decrease

Open the packing box check box products, accessories, complete specifications and the use of manuals, each packing box internal including and package types consistent lighting products a lamp; right out of the box, please check the product is damaged or scratched, labeling and certification is complete.
