LED Street Lights > LD-06

Huazhibei LD-06 series LED street light, using high-quality aluminum die casting shell, simple structure,Streamline design, surface spray treatment, high temperature resistance, good weather resistance; optimal integration.The function of heat dissipation, beautiful appearance; using a unique two optical design of the lens, the whole Light intensity, uniform brightness; high temperature resistant silicone rubber seal, seal better equipped with high;A low loss chip imported light source, high thermal conductivity, low luminous decay, pure light color, no ghosting;Isolation of high precision IC control drive, constant current precision, high conversion rate, longer service life.

Applications: highway, city streets, bridges, tunnels, underground tunnels, underground parking lot, railway square, etc.!

Characteristic Parameter:

Model No.

(W)

Power

(V)

Working Voltage

(λ)

Power Factor

(lm)

Luminous Flux

(Ra)

CRI

(K)

CCT

(IP)

IP Rate

(℃)

ambient temperature

Lamp structure

LD-06-30W

30

AC85-265

﹥0.5

2400

﹥70

2700-6800

65

-20℃~+50℃

10 Series 3 Parallel

LD-06-50W

50

AC85-265

﹥0.9

4000

﹥70

2700-6800

65

-20℃~+50℃

10 Series 5 Parallel

LD-06-70W

70

AC85-265

﹥0.9

5600

﹥70

2700-6800

65

-20℃~+50℃

10 Series 7 Parallel

LD-06-80W

80

AC85-265

﹥0.9

6400

﹥70

2700-6800

65

-20℃~+50℃

10 Series 8 Parallel

LD-06-100W

100

AC85-265

﹥0.9

8000

﹥70

2700-6800

65

-20℃~+50℃

10 Series 5 Parallel * 2

LD-06-120W

120

AC85-265

﹥0.9

9600

﹥70

2700-6800

65

-20℃~+50℃

10 Series 6 Parallel * 2

LD-06-150W

150

AC85-265

﹥0.9

12000

﹥70

2700-6800

65

-20℃~+50℃

10 Series 5 Parallel * 3

LD-06-200W

200

AC85-265

﹥0.9

16000

﹥70

2700-6800

65

20℃~+50℃

10 Series 5 Parallel * 4

Note: the scope of power error is about 10%; the range of flux error is -10%, some warm white luminous flux will decrease;

1.lighting installation, should ensure that the power off state, so as to avoid improper operation caused by electric shock.
2. LED lights will lamp is arranged in the lamp post, will be sufficient length of red and black wire penetrates into the lamp post until placed at the bottom of the pole adjustment angle, fixed with the screws.
3. power input cable of the brown line and power supply terminal phase red) is connected, power input cable of the blue line and the power supply end of the zero line (blue) is connected, power input cable of yellow green wire and grounding protection line (anchor bolts are connected.
4. are firmly connected, and then to do joint insulation, waterproof treatment. To be fully installed check lock electric door, switch on the power, the lamp can work

Electrical connections:
Led street lamp power supply line for the three core cable, which red or brown line is connected with the live wire, blue line connected to the zero line, ground yellow green yarn. After connecting the electrical wire connections need to be waterproof processing, inside the lamp driving and light source connected with the waterproof connector line, easy to maintain and use.

1. in order to ensure the reliable and stable work, lighting, ground wire must be reliable grounding!

2. wiring is completed, must use the insulating tape, which are insulated from each other and reliable to do waterproof processing!

3. fastening screws must be tightened firmly, prevent loosening of lamps.

4.The input voltage can not exceed AC285V, otherwise it will cause irreparable damage!

After-sale service:
If in the deconsolidation of products, installation and use of the process have any questions please contact our customer service department, our company will in response to the fastest speed, troubleshooting, and resume normal work.
Due to incorrect installation, operation or specified in non product working environment, the use of fault or damage caused by the conditions, not our customer service, specifically including the following:
1 because of the accident, misuse, damage caused by misuse;
2 due to failure or damage caused by improper storage or transportation of customers;
3 due to damage to the user without dismantling or replacing the Division has not been recognized by parts;
4 failure or damage to human or natural disasters;
